200T Pressure High Automatic Perforating Machine for Max 20mm Thickness Gypsum Board Punching

200T Pressure High Automatic Perforating Machine for Max 20mm Thickness Gypsum Board Punching

ब्रांड नाम: LVJOE
मॉडल संख्या: LV-CK01
एमओक्यू: 1 सेट
कीमत: US $20000-80000
आपूर्ति करने की क्षमता: प्रति वर्ष 50 सेट
विस्तृत जानकारी
उत्पत्ति के प्लेस:
चीन
प्रमाणन:
ISO CE
प्रोडक्ट का नाम:
ध्वनि इन्सुलेशन बोर्ड छिद्रण उपकरण हाई स्पीड प्लास्टर बोर्ड पंच मशीन
कीवर्ड:
सतत उत्पादन जिप्सम बोर्ड छेदक
दबाव:
80T, 160T, 200T
प्रयोग:
जिप्सम बोर्ड, एमडीएफ, एचपीएल, फाइबर सीमेंट बोर्ड वेध
छेद:
चौराहे पर
स्वचालित स्तर:
उच्च स्वचालित
मोटाई:
अधिकतम। 20 मिमी
गारंटी:
1 वर्ष
आवेदन:
आंतरिक छत और विभाजन
विशेषता:
सामान्य
पैकेजिंग विवरण:
पीई फिल्म लिपटे
आपूर्ति की क्षमता:
प्रति वर्ष 50 सेट
उत्पाद का वर्णन
Sound Insulation Board Perforating Equipment High Speed Plaster Board Punch Machine
High-performance gypsum board drilling equipment designed for precision perforation in various building materials.
Product Specifications
Pressure 80T, 160T, 200T
Usage Gypsum Board, MDF, HPL, Fiber cement board perforation
Holes Round, Square
Automatic Level High automatic
Thickness Max. 20mm
Technical Specifications
  • Punching pressure: 200 ton
  • Stroke: 30 mm
  • Max mold height closed: 260mm
  • Number of strokes: 50 times/minute
  • Slide surface: 210*1100mm
  • Working table: 300*1670mm
  • Spacing of both pole: 1350mm (load the max board width 1220mm)
  • Power of main motor: 22kw
  • Power of servo motor: 2.6kw (brand: Zhejiang yifeng)
  • Feeding accuracy: ±1mm
  • Maximum feeding rate: 100mm
  • Maximum feeding thickness: 20mm
  • Gross weight of machine: 11000kg
  • Overall dimension: 2300*1500*2300(H*L*W)
Applications
This perforation machine is designed for creating holes in various materials including gypsum ceiling board, MgO board, MDF, HPL, Fiber cement board, and metal sheets. Custom hole shapes are available to meet specific requirements. Comprehensive operational training is provided.
Sound Insulation Board Perforating Equipment - High Speed Plaster Board Punch Machine
