जिप्सम छत टाइल उत्पादन लाइन
Created with Pixso.

PLC System Controlled PVC Laminated Gypsum Board Machine with 1300mm Laminating Width and 15m/min Speed

PLC System Controlled PVC Laminated Gypsum Board Machine with 1300mm Laminating Width and 15m/min Speed

ब्रांड नाम: LVJOE
मॉडल संख्या: 1300FM01
एमओक्यू: 1 सेट
कीमत: US $20000-200000
भुगतान की शर्तें: एल/सी,टी/टी
आपूर्ति करने की क्षमता: प्रति वर्ष 50 सेट
विस्तृत जानकारी
उत्पत्ति के प्लेस:
हेबेई, चीन (मुख्य भूमि)
प्रमाणन:
CE ISO 9001
प्रोडक्ट का नाम:
बोर्ड काटने की मशीन और थर्मोप्लास्टिक पैकिंग मशीन बोर्ड पीवीसी लैमिनेटेड जिप्सम बोर्ड छत टाइलें
कीवर्ड:
प्लास्टरबोर्ड टाइल्स मशीन
वोल्टेज:
380V
गारंटी:
1 वर्ष
आयाम(एल*डब्ल्यू*एच):
12600*1950*1600
प्रेरित प्रकार:
पीएलसी प्रणाली
वज़न:
3-30T
विशेषताएँ:
संचालित करने में आसान
पैकेजिंग विवरण:
निर्यात के लिए मानक पैकेज या पीवीसी और पीईटी फिल्म के लिए अनुरोध के अनुसार जिप्सम सीलिंग बोर्ड बनाने
आपूर्ति की क्षमता:
प्रति वर्ष 50 सेट
प्रमुखता देना:

PLC System Gypsum Ceiling Tile Production Line

,

1300mm Laminating Width PVC Laminated Gypsum Board Machine

,

15m/min Laminating Speed Board Cutting Machine

उत्पाद का वर्णन
Board Cutting Machine & Thermoplastic Packing Machine for PVC Laminated Gypsum Board Ceiling Tiles
This fully automatic cutting machine is engineered for PVC laminated gypsum board ceiling tile production, efficiently processing surface decorative materials including films, papers, and laminates for various board types.
Technical Specifications
Attribute Value
Voltage 380V
Warranty 1 Year
Dimension (L*W*H) 12600*1950*1600 mm
Driven Type PLC System
Weight 3-30t
Features Easy To Operate
Machine Capabilities
Parameter Specification
Effective Laminating Width ≤1300mm
Sheet Thickness 5-30mm
Laminating Speed 15m/min
Speed Adjustment Frequency conversion synchronous speed regulating
Electrical Control PLC system
Film Material PVC film, aluminum foils, decorative material
Installed Power 4kw
Standard Gypsum Ceiling Tile Sizes
  • 595*595*8.0mm
  • 603*603*8.0mm
  • 600*1200*8.0mm
Operation Process
The machine precisely cuts laminated gypsum boards to required sizes according to saw gauge standards. Boards are placed on delivery rolls, processed through the cutting system twice for enhanced accuracy, and delivered as finished products. The system can be optionally equipped with a pulsed sack-duster.
Our Manufacturing Advantages
Competitive Pricing
Direct factory production with 15+ years of specialization in PVC laminated gypsum ceiling tile machinery
Superior Quality
Rigorous quality control standards throughout manufacturing
Comprehensive Service
Specialized international trading company focused on export business
Complete After-sales Support
Engineers provide production line design, installation, commissioning, and operator training
