Automatic Rock Wool Panel Production Line with 40~120 meters/min Conveying Speed and 2800mm Swing Belt Width

Automatic Rock Wool Panel Production Line with 40~120 meters/min Conveying Speed and 2800mm Swing Belt Width

ब्रांड नाम: Greens
मॉडल संख्या: रॉक ऊन दीवार पैनल बनाने की मशीन
एमओक्यू: 1
कीमत: US $2000000-4000000
भुगतान की शर्तें: एल/सी, टी/टी
विस्तृत जानकारी
उत्पत्ति के प्लेस:
हेबै
प्रोडक्ट का नाम:
अग्निरोधी गर्मी संरक्षण ध्वनि इन्सुलेशन रॉक ऊन दीवार पैनल बनाने की मशीन
कीवर्ड:
रॉक वूल बिल्डिंग वॉल इंटरलेयर आंतरिक इन्सुलेशन वॉल रॉक वूल उत्पादन लाइन
वोल्टेज:
380V या अनुकूलित
स्पीडिंग स्पीड:
40 ~ 120 मीटर/मिनट
स्विंग बेल्ट चौड़ाई:
2800 मिमी
स्विंग बेल्ट मोटर:
4KW (चर आवृत्ति मोटर)
पैनल मोटाई:
20-250 मिमी
पैनल घनत्व:
30-250 किग्रा/mic
प्रमुखता देना:

fireproof rock wool wall panels machine

,

heat preservation mineral wool production line

,

sound insulation rock wool board maker

उत्पाद का वर्णन
Fireproof Heat Preservation Sound Insulation Rock Wool Wall Panels Making Machine
This advanced production line combines fireproofing, heat preservation, and sound insulation capabilities for manufacturing high-quality rock wool wall panels with automated efficiency.
Key Specifications
Attribute Value
Product Name Drum Collection Machine Wool Collecting And Pendulum System Rock Wool Production Line
Voltage 380v Or Customized
Electric Control PLC control
Condition New
Conveying speed 40~120 meters/min
Swing belt width 2800mm
Swing belt motor 4kw (variable frequency motor)
Technical Specifications
  • Product Name: Rockwool Panel Production Line
  • Automatic Grade: Automatic
  • Voltage: 380V
  • Panel Thickness: 30-200mm
  • Felt Size: 1000mm (adjustable)
  • Panel Density: 30-200 Kg/m3
  • Applicable Industries: Manufacturing Plant, Retail, Construction works
  • Finished products: Rock wool board
  • Usage: Building Material Production
System Components
  • Slag and cotton separation system
  • Cotton collection mechanism
  • Screen cleaning device
  • Cotton lifting system
  • Automatic refueling and lubrication system
  • Automatic slag discharge device
The machine features a sturdy steel structure frame with bearing transmission system. The drum includes a mesh plate with installed negative pressure air induction chamber beneath. The fan creates negative pressure in the induction chamber, effectively pulling cotton fibers onto the stencil while filtering and emptying through the settling chamber.
